Panel
Diagonal Size Class
55
Diagonal Size Measured
54.6
Type
Edge LED BLU
Resolution
UHD (3840 x 2160)
Pixel Pitch (mm)
0.315 x 0.315
Active Display Area
1209.6(H) x 680.4(V)
Brightness(Typ.)
350
Contrast Ratio (Typ.)
4000:1
Viewing Angle(H/V)
178/178
Response Time (G to G)
8ms(Typ.)
Display Colors
16.7M(True Display) / 1.07B(Ditherd 10bit)
Color Gamut
92% (DCI-P3, CIE 1976)
Operation Hour
16/7
Haze
2%
Display
Dynamic C/R
MEGA
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
594MHz
Sound
Speaker Type
Built in Speaker(10W + 10W)
Connectivity
INPUT RGB
DVI-D
INPUT VIDEO
HDMI 2.0 (2)
INPUT HDCP
HDCP 2.2
INPUT AUDIO
Stereo Mini Jack, DVI/HDMI/ Audio(Common)
INPUT USB
USB 2.0 x 2
OUTPUT RGB
N/A
OUTPUT VIDEO
N/A
OUTPUT HDCP
Stereo Mini Jack
OUTPUT AUDIO
N/A
OUTPUT USB
N/A
EXTERNAL CONTROL
RS232C(in/out) thru stereo jack, RJ45
EXTERNAL SENSOR
IR
Tuner
N/A
Power
Type
Internal
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption Max[W/h]
143
Power Consumption Typical[W/h]
108
Power Consumption Rating[W/h]
130
Power Consumption BTU(Max)
487.6
Power Consumption Sleep mode
0.5
Power Consumption Off mode
N/A
Mechanical Spec
Dimension(mm) Set
1235.1 x 707.9 x 46.3
Dimension(mm) Package
1402*585*163
Weight (kg) Set
18.1
Weight (kg) Package
23.6
VESA Mount
200 200x
Protection Glass
N/A
Stand Type
Foot Stand (Optional)
Bezel Width (Top/Side/Bot) (mm)
9.2mm(U/L/R), 11.2mm(B)
Operation
Operating Temperature
0℃~ 40℃
Humidity
10~80%
Feature
Key
UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
Special H/W
Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), IP5x Rating, Wi-Fi/BT
Special S/W
Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player (Embedded H/W)
Processor
Coretex A72 1.7GHz Quad-Core CPU
On-Chip Cache Memory
L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
Clock Speed
1.7GHz
Main Memory Interface
2.5GB LPDDR4 1.5GHz 64bit
Graphics
Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)
Storage (FDM)
8GB (3.88GB Occupied by O/S, 4.12GB Available)
Multimedia
*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG
IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Certification
Safety
60950-1
EMC
Class B
Environment
ENERGY STAR 8.0, Epeat
Security
802.1x(WPA2 Enterprise) (‘20.1~) : EAP-TLS, EAP-TTLS, EAP-PEAP
Accessories
Included
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional Stand
STN-L4355F
Optional Mount
WMN4070SE (Land Only)
Optional Specialty
CML400XK
Optional Media Player
N/A
